Bluetooth adapter for Volthium batteries only. The Bluetooth dongle communicates with the battery's BMS to broadcast, via its internal Bluetooth chip with a 40 feet unobstructed range, the data broadcasted by the data port on the battery.
Compatible batteries are :
All 12V100AH batteries with an XLR communication port on top
All 12V200AH batteries with two XLR communication ports on top
All 12V300AH batteries with two XLR communication ports on top
All 12V400AH batteries with RJ45 ports
All WALLMOUNT 24V200AH batteries with one XLR communication port on the front.
All batteries with a yellow top (2022 or newer
This Bluetooth dongle has a total of 3x RJ45 female ports, and one DC input port.
The DC port (green) is for power supply. The accepted voltage is in the range of 10V to 59V.
The RJ45 port, on the same side as the DC connector, is used in case only one battery is to be monitored with the Bluetooth module.
Do not connect a battery to this port if the Bluetooth module is used with the Communication HUB module.
Series of 2 RJ45 ports (Daisy-Chain CAN)
They are used to interconnect the Volthium boxes on the CAN network
For example; The "Communication HUB" box, which would be used to connect a battery bank (energy bank)
Could also be used to connect the "Closing Loop", which is a small black RJ45 connector.
